EFAF260Coil Packing Line with Circumferential Film Package

Product Overviews :

Used for circumference thermo shrink packaging and palletizing, and wrapping PE film after wire coilers on the pallet with automatic operation.

Technical Specification :

Consist of flyer pay-off, spark tester, MAC260 coiler, strapping machine, thermal shrink packaging machine, sleeve sealing machine(circumference), labeling machine, automatic palletizing machine and wrapping machine. It's a high cost performance coiling packaging and palletizing system.


Main Parameters:

1. Suitable for conductor: Ф0.75mm²-6.0 mm²
2. Suitable for cable diameter: Ф2.0mm-5.0 mm
3. Coiling speed: Max 4 coils/min, 100m/coil
4. Strapping times: 2 times/coil
5. Coiler packaging size: ODФ240mm,IDФ150mm,H:35~100 mm
6. Packaging material: PE thermal film
7. Pallet size: 1200*800


Higher economic, Higher efficiency, Higher environmental, best solution of upgrading on automatic for your machine.
