Technical Specification :

EXJ90/35+65 line is consist of 90mm extruder and 30mm extruder for the extrusion. Another 65mm extruder will be for the extrusion of nylon shealth. The pay-off is with double barrel without stop and switch automatically.


Main Parameters:

●    Conductor: 10-18AWG
●    Diameter over insulation: 2.0mm-5.0mm
●    Concentricity: ≥92%
●    Compound: PVC/XLPE/PA6
●     90mm extruder: Max 400kg/h (PVC)
●    35mm extruder: Max 50kg/h (PVC)
●    65mm extruder: Max 110kg/h (via bypass  PA6)
●    Line speed: Max 1000m/min



SPC quality statistics to improve the quality of products and improve the production. Perfect management of process recipe is the guarantee for consistency and standardization of production, and minimize the dependence of people.
