SINGCHEER received the honour awarded by Jiangsu machinery industry

2016-11-23

On the basis of awarding measures of Jiangsu machinery industry science and technology progress award, the evaluation committee of 2016 Jiangsu machinery industry science and technology progress award announced 96 awards, including first prize 25, two prize 34 and third-prize 37.

Dual coiler take-up with pulling and dancing wheel device itself designed by  Singcheer and it is popular with customers. The take up reel is put on one rotation platform, shift by rotating the platform without stop or reduce the line speed. with pulling and dancing wheel device itself. The take up reel is put on one rotation platform, shift by rotating the platform without stop or reduce the line speed.

All the action like wire inlet, wire press, meter counter, wire layout, wire take-up, wire cut, reel change, full reel transport and empty reel transport are controlled by the PLC system. And may add auto strapping machine according to the automation requirements.

Main parameter:
1、 Suitable conductor: 0.22mm2-6.0mm2;
2、 Suitable wire dia.: Ф1.0mm-Ф5.0mm ;round cable
3、 Coil size: OD350*ID200*H100mm
4、 Tension range: 8N-80N
5、 Length counting accuracy: +/-3‰
6、 Speed: Max 1200m/min

Especially in the technology driven industry, you can only be replaced by competitors if there is no innovation. With a professional technical team, SINGCHEER will keep innovation and continue to create greater value for our customers.
